Atex Electric chain hoist

This is an electric chain hoist designed for operation in potentially explosive atmospheres, certified in accordance with ATEX Directive 2014/34/EU.
It is intended for use in gas explosive atmospheres (Zone 1, Zone 2) and dust explosive atmospheres (Zone 21, Zone 22).
The hoist is constructed with explosion‑protected components, non‑sparking features, and temperature‑ limited surfaces to prevent ignition risks.
It is typically used in marine, offshore oil gas, chemical, petrochemical, pharmaceutical, food processing, and cleanroom industries.

• ATEX certified for Zone 1, 2 (gas) and Zone 21, 22 (dust) .
• Explosion‑protected design without ignition sources.
• Fail‑safe electromagnetic spring‑applied brake.
• Mechanical overload clutch for overload protection.
• Integrated upper and lower travel limit switches.
• Oil‑bath lubricated gearbox.
• Robust aluminium housing.
• Non‑sparking components and fully enclosed electrical system.

------ 400V 3Ph 50Hz Type------
• Capacity 125kg:
Falls= 1.Chain=4×12.2mm , W=17kg. Class= 3m/M6 , V= 8m/min , Motor= 0.37kW , ED= 75% .

• Capacity: 250kg :
Falls= 1 , Chain=4×12.2mm , W= 17kg. Class= 1Am/M4 , V= 8m/min , Motor= 0.37kW , ED= 50% .

• Capacity : 320kg :
Falls= 1 , Chain=5×15.1mm , W= 26kg. Class= 3m/M6 , V= 8m/min , Motor= 0.75kW , ED= 67%.

• Capacity : 500kg :
Falls= 2 / 1 , Chain=4×12.2mm /5×15.1mm, W= 20kg / 26kg. Class= 1Am/M4 , V= 4m/min / 8m/min , Motor= 0.37kW / 0.75kW, ED= 50% .

• Capacity :630kg :
Falls=: 1 ,Chain=7.1×20.5mm , W= 58kg. Class= 3m/M6 , V= 8m/min , Motor= 1.5kW , ED= 67%.

• Capacity : 1000kg:
Falls= 2 / 1 ,Chain=5×15.1mm / 7.1×20.5mm, W= 28kg / 58kg. Class= 1Am/M4 , V= 4m/min / 8m/min , Motor= 0.75kW / 1.5kW , ED= 50%.

• Capacity : 1500kg :
Falls= 2 ,Chain=7.1×20.5mm , W= 63kg. Class= 2m/M5 , V= 4m/min , Motor= 1.5kW , ED= 62%.

• Capacity : 2000kg :
Falls= 2 ,Chain=7.1×20.5mm , W= 63kg. Class= 1Am/M4 , V= 4m/min , Motor= 1.5kW , ED= 50%.

------230V 1Ph 50Hz Type------
• Capacity : 125kg : Falls= 1 ,Chain=4×12.2mm , W= 25kg. Class= 3m/M6 , V= 4m/min , Motor= 0.37kW , ED= 35%.

• Capacity : 250kg :
Falls= 1 ,Chain=4×12.2mm , W= 25kg. Class= 1Bm/M3 , V= 4m/min , Motor= 0.37kW , ED= 25%.

• Capacity : 500kg :
Falls= 2 / 1,Chain=4×12.2mm / 5×15.1mm ,W= 25kg. Class= 1Bm/M3 , V= 2m/min / 8m/min , Motor= 0.37kW / 1.0kW, ED= 25%.

• Capacity : 1000kg :
Falls= 2 ,Chain=5×15.1mm ,W= 25kg. Class= 1Bm/M3 , V= 4m/min , Motor= 1.0kW , ED= 25%.
