• Capacity: 500-2000kg (Customizable on request). • Lifting height: 2060-2490mm. • Jib length: 750-1460mm (3-position extendable). • Manual operation with hydraulic pump. • High compatibility: standard 360° swivel hook, overload safety valve, controlled descent device. • Meets or exceeds global mechanical safety standards.   Options: • Individually Tested to 1.25% of Maximum Capacity. • Anti-corrosive painting; • Stainless steel version available. • DNV, BV, ABS, CCS certification. • TUV, GS, CE, SGS, CQCcertification. • ATEX, explosion-proof version available.

• Capacity: 250-2000kg (Customizable on request).• Lifting height: 2080-2730mm.• Jib length: 920-1610mm (3-position extendable).• Manual operation with heavy-duty double acting pump.• High compatibility: 360° swivel hook, overload safety valve, nylon wheels for easy movement.• Meets or exceeds global mechanical safety standards.Options:• Individually Tested to 1.25% of Maximum Capacity.• Anti-corrosive painting;• Stainless steel version available.• DNV, BV, ABS, CCS certification.• TUV, GS, CE, SGS, CQCcertification.• ATEX, explosion-proof version available.

Capacity: 500kg (goods WLL), 250kg (personnel WLL, up to 3 persons). Quick-release pins for tool-free assembly. Foldable design for compact stowage.Lightweight & Portable: Weighs only 33kg. Standard Beam Lengths: 2000mm / 2376mm / 4000mm. Span (Min-Max): 1100-1750mm / 1200-1800mm / 2700-3500mm. Height (Min-Max): 1785-2095mm / 1850-2050mm / 2028-2928mm. Certified to EN795 Class B, OSHA, ANSI, CSA standards. Notified body approval: SGS UK (0120).Option: • Custom long dimension configurations. • Winching system for load handling. • Non-standard product customization.• ATEX, explosion-proof version available.

Dual-rated for goods & personnel lifting; Goods WLL: 500–5000kg;Personnel WLL: max 2000kg (3–5 persons);Beam length: 2500–9000mm (WLL dependent); S/M/I/T standard sizes available; Total safety: Notified Body approval, CE & EN795 Class B certified; type tested at UKAS labs; Lightweight & portable, easy on-site assembly within manual handling guidelines.   Options:• customizable A-frame (cart/legs);• All Terrain castors for uneven ground;• ATEX Zone 2 standard; Zone 1 upgrade; power feeding line + main isolator;• Geared wheel/Ratchet for height adjustment; • stainless steel/custom materials;• Bespoke solutions, custom beam lengths, electrical configs; multi-certification options.

• Capacity: 250-2000kg.Available for 3000kg.• Outstrench up to 2082mm, Height up to 2463mm.• 360° rotation• Each parts is less than 25kg for PD250, PD500, PD1000• Easy installing with only 7 steps. no tools required• Multiple mounted method: Pedestal/Flush/wall mount/wheel base• Meets or exceeds EN13157 (Euro), ASME B30.16 (American), AS1418.2 (Australian) and other worldwide standards.Option:• Worm gear drive• anti-corrosive painting• stainless version available• DNV, BV, ABS, CCS certification• TUV, GS, CE, SGS, CCS, CQC, CNAS, IAF...• ATEX, explosion-proof version available

• Capacity: 500-2000kg (Customizable on request). • Lifting height: 2060-2490mm. • Jib length: 750-1460mm (3-position extendable). • Manual operation with hydraulic pump. • High compatibility: standard 360° swivel hook, overload safety valve, controlled descent device. • Meets or exceeds global mechanical safety standards.   Options: • Individually Tested to 1.25% of Maximum Capacity. • Anti-corrosive painting; • Stainless steel version available. • DNV, BV, ABS, CCS certification. • TUV, GS, CE, SGS, CQCcertification. • ATEX, explosion-proof version available.

Capacity:  500–5000kg. (Customizable on request) Lifting height: 2--10m Jib length: 2--10m Slewing degree: 0--270° Power supply: 220–690V, 50/60Hz, 3 Phase or customized design Manual slewing High compatibility: easily integrated with Demag, SWF, Yale, CM and other branded hoistsMeets or exceeds EN13157 (Euro), ASME B30.16 (American), AS1418.2 (Australian) and other worldwide standards.Option: Special voltage and electrical configuration; Anti-corrosive painting; Stainless steel version available; DNV, BV, ABS, CCS certification; TUV, GS, CE, SGS, CQC, CNAS, IAF certification; ATEX, explosion-proof version available.

Capacity: Up to 2000kg (available  for 3000kg.)Lift height: 3--10mRadius (Span): 2--6mControl way: Pendant / Remote ControlManual slewingLow noiseLightweight, reliable structure complying with national standards.Meets or exceeds EN13157 (Euro), ASME B30.16 (American), AS1418.2 (Australian) and other worldwide standards.Options: Slewing angle: 180° or 270° Cantilever customization Customizable configurations (load capacity, boom length, hoist type)  Easily integrated with Demag, SWF, Yale, CM.... hoist

Capacity: 3.2 -- 20t, up to 50t on request.Working temp range: –40°C to +60°C.Mass: 39-165kg.Chain mass: 2.2kg/m -- 17.6kg/m.Falls: 1-8 falls (depends on WLL).ROV operable for subsea & offshore lifting.Patented quad-pawl fail-safe brake standard.Safety factor 4:1, proof test 1.5×WLL.2% WLL light load certified.Fleeting/cross hauling approved to 60° without derating.Subsea immersion: single 90 days / multi 60 days total.Operating effort 50Nm, max ROV speed 140rpm.Complies with BS EN 13157, ASME B30.16, AS1418.2, SANS 1594, NORSOK R-002.Marine corrosion resistant, easy maintenance.Options:• ROV interfaces: D‑handle, T‑handle, fishtail, torque bucket (ISO 13628‑8 class 1–4).• Chain bags.• ROV shank hooks.• Shackles & clevis shackles.• Overload limiters.

Working Load Limit (WLL) options: 3t, 5t, 10t, 15t, 20t.Mass (3m HOL, out of water): 65-187kg.Chain mass: 2.24kg/m -- 17.92kg/m (depends on WLL).Falls: 1-8 falls (depends on WLL).Load chain diameter: 10.0mm (all models).Max hydraulic system pressure: 210 bar. Motor speed up to 140 rpm.Temperature range: –40°C to +60°C. Hydraulic connection: Quick disconnect coupling for hot stab tool operation.Patented quad‑pawl fail‑safe brake as standard. Safety factor 4:1, proof tested to 1.5 × WLL. Light load capability certified at 2% of WLL. Certified for fleeting/cross hauling up to 60° from vertical without derating. Compliant with BS EN 13157, ASME B30.16, AS1418.2, SANS 1594, NORSOK R‑002. Marine corrosion‑resistant 316L stainless steel and specialist coatings. Simple maintenance, accessible components for long service life.Options:• ROV hydraulic interfaces: Hot Stab, Quick Disconnect (QD) coupling.• Hand wheel extension bar for topside manual adjustment.• ROV shank hooks.• Shackles & sling hooks.• Overload limiters.• Chain bags.

Working load limits: 1t, 2t, 3t, 6t, 10t, 15t.Proof test: 1.5 × WLL for 1t–10t; 1.25 × WLL for 15t.Light load capability tested and certified at 2% of rated WLL.Load chain: Grade T (8) in accordance with BS EN818-7.Standard lift: 1.5m HOL; extra weight per metre available per capacity.Mass (1.5m HOL): 6kg to 95kg depending on capacity.Full compliance with subsea immersion policy and offshore lifting standards.Suitable for fleeting/cross hauling up to 60° from vertical without WLL derating.Temp Range: -40°C to +120°C.Safety factor 4:1.Complies with BS EN13157, ASME B30.16, AS1418.2, SANS 1594 and NORSOK R-002; verified by DNV-GL.Options:• Overload limiters.• Top and bottom hooks with ball bearing adaptors.• Shackles & sling hooks.• Chain bags.

Capacity: 1t, 2t, 3.5t, 5t, 7.5t, 10t, 12t, 15t, 20t (over 12t are not held in stock and are manufactured upon request).Proof load: 1.5 times the working load limit (WLL).Safety factor: 4:1.Standard lift: 3m HOL; extra weight per metre available per capacity.Load chain: Grade T (8) in accordance with BS EN818-7.Temperature range: -40°C to +120°C.Corrosion protection: ISO 12944 Category C5 marine paint.End stops: fitted as standard.Lifting points: Grade 8 at all four corners.Applicable standards: ASME B30.20 Chapter 6 Clamps, EN13157:2004 + AI:2009.Options:• Overload limiters (available on request).• Chain bags (available on request).• Overload limiters (available on request).

Capacity range: 0.25t, 0.5t, 1t, 1.5t, 2t, 3t, 4t, 5t, 6t, 8t, 10t, 12t.Proof load: 1.5 times the working load limit (WLL).Safety factor: 4:1.Standard lift: Up to 10 ft (3 m), other lengths available on request.Compliance: ATEX 2014/34/EU, 99/92/EC, ASME B30.16, CE.Protection classification: II 2 GD c IIC T4.Load chain: Stainless steel.Hand chain: Stainless steel.Hooks: Copper-coated, drop-forged steel with safety latches.Meets or exceeds EN 13157 (European), ASME B30.16 (American), and relevant international standards for safe operation in explosive atmospheres.Options:• Optional overload protection device.• Chain container for excess chain storage.• Beam locking device to secure hoist on beam.• Additional corrosion protection coating.• Integrated push or geared trolley for beam mounting.

Models: Push Trolley Type• Capacity: 0.5 ton, 1 ton, 2 ton, 3 ton, 5 ton.• Net Weight (Without Lock): 22 kg -- 85 kg (varies by capacity).• Net Weight (With Lock): 30 kg -- 95 kg (varies by capacity).• Number of Chains: 1 chain (≤3 ton), 2 chains (5 ton).• Chain Mass (Per Meter, Load Chain): 1.2 kg/m - 4.5 kg/m.• Max Beam Thickness: 0.9 m (≤1 ton; 1.15 m (2 ton); 1.25 m (3 ton); 1.5 m (5 ton).Models: Geared Trolley Type• Capacity: 0.5 ton, 1 ton, 2 ton, 3 ton, 5 ton, 10 ton, 20 ton.• Net Weight (Without Lock): 25 kg -- 280 kg (varies by capacity).• Net Weight (With Lock): 33 kg -- 300 kg (varies by capacity).• Number of Chains: 1 chain (≤3 ton), 2 chains (5 ton), 3 chains (10 ton), 6 chains (20 ton).• Chain Mass (Per Meter, Load Chain): 1.2 kg/m - 12.0 kg/m.• Max Beam Thickness:  0.9 m (≤1 ton; 1.15 m (2 ton); 1.25 m (3 ton); 1.5 m (5 ton), 2.0 m (10 ton); 2.5 m (20 ton).Models: Low Headroom Geared Trolley Type• Capacity: 0.5 ton, 1 ton, 2 ton, 3 ton, 5 ton, 10 ton.• Net Weight (Without Lock): 24 kg -- 110 kg (varies by capacity).• Net Weight (With Lock): 32 kg -- 120 kg (varies by capacity).• Number of Chains: 1 chain (≤3 ton), 2 chains (5 ton), 3 chains (10 ton).• Chain Mass (Per Meter, Load Chain): 1.5 kg/m - 12.0 kg/m.• Max Beam Thickness:  0.9 m (≤1 ton; 1.15 m (2 ton); 1.25 m (3 ton); 1.5 m (5 ton), 2.0 m (10 ton).General Parameters:• Standard Lifting Height: 3m (customizable).• Operating Temperature: -20°C to +40°C.• Protection Class: IP54.• Standards: ASME B30.16, CE, ATEX.• Single chain for ≤3 ton, multiple chains for ≥5 ton.Options:• Stainless Steel Chain: Corrosion-resistant, suitable for humid/marine environments.• Load Limiter: Automatic overload prevention.• Chain Container: Tidy storage and pollution prevention.• Beam Locking Device: Fix the trolley position (e.g., ship berthing).• Bronze Wheels: Explosion-proof and spark-proof.

• Capacity: 0.125 ton -- 5.0 ton.• Number of falls: 1 -- 2.• Supply voltage: 380 -- 480 V, 3‑phase, 50/60 Hz.• Control voltage: 42 V SELV.• ATEX gas marking: II 2G Ex h IIC T4 Gb.• ATEX dust marking: II 2D Ex tb IIIC T135°C Db.• Maximum surface temperature: ≤ 135 °C.• Protection class: IP55.• Insulation class: F.• Duty cycle: 50% ED.• Standard lifting height: 3 m.• Load chain diameter: 4.0 mm -- 11.3 mm.• Suitable for standard industrial girder profiles.Options:• Dual‑speed execution (ATEX).• Manual push/pull trolley for standard I‑beams.• Explosion‑protected electric trolley.• Low headroom design.• Extended lifting heights.• Stainless steel load chain.• Spark‑resistant surface treatment.• ATEX‑certified pendant control.• Additional upper and lower limit switches.

• Capacity: 0.125 ton -- 1.0 ton.• Number of falls: 1 -- 2.• Operating air pressure: 4 -- 6 bar.• ATEX gas marking: II 2G Ex h IIC T4 Gb.• ATEX dust marking: II 2D Ex tb IIIC T135°C Db.• Maximum surface temperature: ≤ 135 °C.• Protection class: IP65.• Duty cycle: 100% continuous operation.• Standard lifting height: 3 m.• Load chain diameter: 4.0 mm -- 7.1 mm.• Suitable for standard crane and I‑beam installations.Options:• Manual push/pull trolley.• ATEX‑certified pneumatic trolley.• Extended lifting heights.• Spark‑resistant and corrosion‑resistant coatings.• ATEX‑compliant pull‑cord control.• Emergency stop function.• Stainless steel load chain.

Capacity: 500-3000kg (Customizable on request).Max working angle: 0-15° from vertical.The clamp serves as an anchor or lifting point when attached to an overhead steel angle section approved for lifting applications.The V-Block clamping jaw ensures that the clamp is securely fixed to the angle section when adequately tightened.High compatibility: easily integrated with various hoists.Meets or exceeds BS EN 13155:2003+A2:2009, AS4991, Machinery Directive 2006/42/EC and other worldwide standards.Recommendation:We advise that structural calculations are carried out on all beams and supporting steel work by qualified engineering departments to ensure safe operation.Option:• Anti-corrosive painting;Stainless steel version available;• DNV, BV, ABS, CCS certification;• TUV, GS, CE, SGS, CQC, CNAS, IAF certification;•  ATEX, explosion-proof version available;• Operating temperature -40°C to +80°C (temperature range of -60°C to +80°C available as an option).

Capacity: 3000 -- 5000kg and 10000kg available  (Customizable on request).Beam width: 125 -- 400mm.Net weight: 13.5 kg -- 43.1 kg.125% overload proof load tested.Full rated capacity at any lifting angle.Low headroom design for tight applications.Multidirectional adjusting screw spindle ensures high clamping force.Easy and quick clamping/unclamping, no extra tools required.Meets or exceeds EN13155:2003+A2:2009, ASME B30.20 and other worldwide standards.WARNING: Do Not Exceed Working Load Limits or use this equipment for lifting Flat Plate Sections (not to be used as a plate lifting clamp)Option:• NEW  10ton deep flange option;• Anti-corrosive painting;Stainless steel version available;• DNV, BV, ABS, CCS certification;• TUV, GS, CE, SGS, CQC, CNAS, IAF certification;• ATEX, explosion-proof version available;• Operating temperature -40°C to +80°C (temperature range of -60°C to +80°C available as an option).

Capacity: 1000kg -- 10000kg.Beam clamp incorporating adjustable mechanism for beam ranges: 75 -- 320mm. Net weight: 3.8kg -- 17.2kg.Safety factor up to 5 times SWL.These units meet and exceed all the requirements within BS EN 13155:2003+A1:2009 and AS4991.WARNING: • Must be tightened with socket and wrench.Option:• Optional locking device.• Material customization available: carbon steel, stainless steel (304/316).• Anti-corrosive painting;Stainless steel version available;• DNV, BV, ABS, CCS certification;• TUV, GS, CE, SGS, CQC, CNAS, IAF certification;• ATEX, explosion-proof version available.

Capacity: 200kg -- 3048kg.Beam clamp incorporating adjustable mechanism for beam ranges: 114 -- 300mm. Net weight: 6kg -- 16kg.For top beam flange use only.125% overload proof load tested.Meets or exceeds EN13155:2003+A2:2009, ASME B30.20 and other worldwide standards.WARNING: • Do Not Exceed Working Load Limits or use this equipment for lifting Flat Plate Sections (not to be used as a plate lifting clamp).• Must be tightened with socket and wrench.Option:• Anti-corrosive painting;Stainless steel version available;• DNV, BV, ABS, CCS certification;• TUV, GS, CE, SGS, CQC, CNAS, IAF certification;• ATEX, explosion-proof version available.
